AP-23
APPENDIX 5 PARTS LIST
This equipment contains complex modules in which fault diagnosis and repair down to component
level are not practical (IMO A.694(17)/8.3.1). Only some discrete components are used. FURUNO
Electric Co., Ltd. Believes identifying these components is of no value for shipboard maintenance;
therefore, they are not listed in this manual. Major modules can be located on the parts location
photos on pages AP-25 thru AP-27.
Transceiver Unit FS-1575T
Unit
Model
Code No.
ELECTRICAL PARTS LIST
FS-1575
Transceiver Unit FS-1575T
05P0864A, PA-IF
05P0868, 150WPA
05P0874, PWR
05P0847A, WR1
05P0856, TX
05P0842, RX
05P0862B, RX-FIL
05P0861A, T-IF
05P0860, MOT
05P0859, T-CPU
05P0871, P-SW
05P0847B, WR2
05P0876, 150WTX-FIL
PRINTED CIRCUIT BOARD
To Next Page
