3. PLOTTER OPERATION
3-46
Selecting an external waypoint
You can select a waypoint (or route) entered at an external plotter connected
with NMEA cable. This function requires RMB sentence.
1. Press the [MENU] key, PLOTTER SETUP soft key to show the PLOTTER
SETUP menu.
2. Use the trackball to select QP.
3. Press the ENTER soft key or [ENTER] knob to show the QP window.
QP
¡
EXT WPT (RMB)
¤
INTERNAL
QP window
4. Select EXT WPT (RMB).
5. On a connected external plotter, set a waypoint (or route) as the destination.
Selected waypoint (route) appears on the NavNet plotter screen. (on radar
screen, a lollipop appears to show the waypoint.)
3.10.3 Navigating to ports, port services (NavCharts™/C-MAP)
NavCharts™/C-MAP have a port service list which shows services available at
ports or harbors. (See page 3-13.) You can use the list to set your destination as
follows:
1. Select “35 PTS/PORT SVC” following the procedure in “Selecting quick point
entry method” on page 3-44.
2. Place the cursor on the location desired, then press the GOTO soft key. Soft
key titles change as in the figure below.
FROM
OS
0.26 nm
180.2°M
PUNTA CORNACCHIA
ACCO AMENO
I. ISCHIA
CASAMICCIOLA
ISCHIA
PORTO
40°45.971'N
13°57.462'E
+
QUICK
ROUTE
NEAR
SRVC
PORT*
CANCEL
GOTO
GOTO
16.0nm
*NavCharts only
TM
Plotter display
3. Press the PORT (NavCharts™ only) or NEAR SRVC soft key depending on
objective. PORT shows a list of ports in your area. NEAR SRVC displays the
port service list.
To Next Page
