Furuno MARINE RADAR 1823C User Manual

2. RADAR OPERATION
2-43
TCPA
▲
¡
¡
¡
¡
¡
¡
¡
▼
¤
30 seconds
1 minute
2 minutes
3 minutes
4 minutes
5 minutes
6 minutes
12 minutes
TCPA window
8. Select a TCPA limit from 30 sec, 1 min, 2 min, 3 min, 4 min, 5 min, 6 min and
12 min.
9. Press the ENTER soft key.
10. Press the [MENU] key to close the menu.
2.26.9 Lost target alarm (ARP)
When the system detects a lost target, the target symbol becomes a diamond
and tracking is discontinued after one minute.
01
Lost target mark
Canceling a lost target
1. Place the cursor on the target.
2. Press the [CLEAR] key.

Furuno MARINE RADAR 1823C Specifications

General

Type	Marine Radar
Display Size	10.4 inches
Resolution	800 x 600 pixels
Power Output	4 kW
Antenna Type	Open Array
Rotation Speed	24 RPM
Frequency	9410 MHz (X-band)
Display	LCD
Power Supply	12/24 VDC
Range Scales	0.125, 0.25, 0.5, 12, 24, 48 nautical miles
