6. MAINTENANCE, TROUBLESHOOTING
6-16
6.7 How to View the Sensors in Use
The [View Sensors In Use] menu provides a comprehensive list of the sensors con-
nected to your NAVPILOT. To show the [View Sensors In Use] menu, follow the pro-
cedure below.
1. In STBY, AUTO, NAV or OVRD mode, press to open the menu.
For Safe Helm, press then select [MENU] from the [TURN] menu.
2. Select [View Sensors In Use]. The list of sensors used as a data source appears.
The display shows the device used as the source for each data type with the de-
vice instance and unique CAN ID for the source device.
Dashed lines indicate no connection or sensor is not currently active.
3. Close the menu.
32 2014 NAV mode complete.
Switching modes.
NAV mode has completed and the sys-
tem has switched to different mode.
u
33 2017 Helm sensor error. There is a problem with the helm sensor
data. Check the helm sensor status.
9
34 2015 Deviation alert. Detected a deviation from the set course
(see section 3.3). Adjust heading ac-
cordingly.
u
35 2016 Watch alert! The watch alert was released (see
section 3.2). Press any key.
u
Prio
rity
Error
Code
Message Meaning/remedy
Alert
Log
View Sensors In Use View Sensors In Use
HDG:
POS:
STW:
Device name
Device instance CAN unique ID
Current data source
----------------------
1
1
Prev Prev
▼
NAV:
SOG:
▼
----------------------
TZTL12F : 0: 000C2F
----------------------
TZTL12F : 0: 000C2F
To Next Page
