2. WIRING
2-12
Output PGN
The NMEA 2000 output PGN setting (found under the [Initial Setup] menu) is global to
the network. Note that only one TZT2BB will output NMEA 2000 data on the network
at a time: the TZT2BB which is powered ON first. If that display is turned OFF, another
will take its place to output the data.
129041 AIS Aids to Navigation (AtoN) Report
129291 Set &Drift, Rapid Update
129538 GNSS Control Status
129540 GNSS Satellites in View
129793 AIS UTC and Date Report
129794 AIS Class A Static and Voyage Related Data
129795 AIS Addressed Binary Message
129797 AIS Binary Broadcast Message
129798 AIS SAR Aircraft Position Report
129801 AIS Addressed Safety Related Message
129802 AIS Safety Related Broadcast Message
129808 DSC Call Information
129809 AIS Class B "CS" Static Data Report, Part A
129810 AIS Class B "CS" Static Data Report, Part B
130306 Wind Data
130310 Environmental Parameters - DEPRECATED
130311 Environmental Parameters - DEPRECATED
130312 Temperature - DEPRECATED
130313 Humidity
130314 Actual Pressure
130316 Temperature, Extended Range
130576 Trim Tab Status
130577 Direction Data
130578 Vessel Speed Component
130817 Furuno GNSS Control Status
130818 Heading & Attitude Sensor Control Status
130820 Motion Sensor Status
130822 Unit Division Code
130823 Browser Control Status
130826 Multi Sats In View
130827 NAVpilot General Message
130828 Mark Position Information
130845 Multi Sats in View Extended
130846 Motion Sensor Status Extended
130848 WaterCurrent Layer
130880 Additional Weather Data
PGN Description Output cycle (msec)
059392 ISO Acknowledgment
059904 ISO Request
060928 ISO Address Claim
061184 Self Test Group Function
065287 HID Target Status 5000
PGN Description
