2. WIRING
2-15
Mid/Large-size vessels (External GPS, Fish Finder, Radar)
This is a single station plotter/radar/fish finder installation. Connection to multiple sen-
sors, such as the DFF3-UHD and DRS series, requires an Ethernet hub such as the
HUB-101.
GPS RECEIVER
GP-330B
*
3
Radar Sensor
DRS6A X-Class, DRS12A X-Class,
DRS25A X-Class, DRS6A-NXT,
DRS12A-NXT, DRS25A-NXT
Radar Sensor
DRS4DL+, DRS4D X-Class
DRS2D-NXT, DRS4D-NXT
12 to 24 VDC
12 to 24 VDC
12 to 24 VDC
Two-way cable
(MOD-ASW0001/ASW002)
*
1
: The HUB-101 is required when two or
more pieces of network equipment are
connected to the TZTL unit.
*
2
: Local Supply
*
3
: Backup
OR
NMEA 2000 backbone cable
NMEA 2000
drop cable
Remote Control
Unit
MCU-002
SD Card Unit
SDU-001
Remote Control
Unit
MCU-002
SD Card Unit
SDU-001
Optional LAN cable
MOD-Z072/Z073,
2 m, 3 m, 5 m, 10 m
LAN cable
MOD-Z072
Network Fish Finder
DFF3-UHD
Cable Assy.
FRU-2P5S-FF
HUB-101*
1
DFF3
NETWORK SOUNDER
ST-BY
USB Hub*
2
USB Hub*
2
NMEA 2000
drop cable
Processor Unit
MPU-004
Processor Unit
MPU-004
High
freq.
Low
freq.
12 to 24 VDC
12 to 24
VDC
