FURUNO VR-3000/VR-3000S
SP - 1 E4437S01D-P
SPECIFICATIONS OF
VOYAGE DATA RECORDER VR-3000/
SIMPLIFIED VOYAGE DATA RECORDING VR-3000S
The Voyager Data Recorder (VDR) is a recording system required on certain categories of ships
from 1
st
July 2002 by the revised SOLAS Chapter V. The Simplified Voyager Data Recorder
(S-VDR) is a recording system required by IMO MSC.163(78). VR-3000 fully complies with the IMO
Resolution A. 861 (20) and IEC 61996 testing standard. VR-3000S fully complies with the IMO
MSC.163(78) and IEC/PAS 61996 testing standard.
1 GENERAL
1.1 Recording Period DRU: 12 hours, Backup HDD: 12 hours x 4 recording areas
1.2 Battery Backup More than two hours after loss of ship’s mains
2 DATA COLLECTING UNIT (DCU): VR-3010
2.1 CPU Intel Pentium M 1.6GHz
2.2 Memory 512 Mbyte
2.3 Input Signal
Input signal VR-3000 VR-3000S Remarks
Bridge audio 6ch 6ch 775mV AC/600 ohms
VHF audio 2ch 2ch 775mV AC/600 ohms
Serial data IEC 61162-2 4ch 2ch(+2ch*)
Serial data IEC 61162-1 12ch 6ch(+6ch*)
Radar image Std. 1ch
(+3ch*)
Max. 4ch* RGBHV signal
Analog signal Std.16ch,
Max. 48ch*
Max. 48ch* -10 - +10V,
0 - +10V,
4 - 20mA
Digital signal Std. 64ch,
Max. 192ch*
Max.192ch* Contact signal,
Voltage signal (10 -32V)
Remote ACK signal 1ch 1ch
Output signal VR-3000 VR-3000S Remarks
Ethernet 100Base-T 2ch 2ch
VDR System Fail signal 1ch 1ch
Local ACK signal 1ch 1ch
IEEE1394a 1ch 1ch For data extraction
* : Option
3 DATA RECORDING UNIT (DRU): VR-5020
3.1 Chassis Protective capsule
3.2 Memory Capacity 6 GB or 9 GB
