700 Series CONNECTION EXAMPLE SETTING UP THE 700 Series
ZONES
Zone1and2arepoweredbytheonboardClass-Damplifier.External
amplifiersarerequiredtoutilizethe4lineoutputsand4subwooferoutputs.
You can pre-set the balance, volume limit, sub-woofer level and name for each of the
fourZonesavailableonthe700Series.Ifrequired,youcanalso:
• EnableordisableZones2,3and4(Zone1isalwaysenabled).
• Enableordisablevolumecontrol(Zones3and4only).
• LinkZones1and2.
For further details, see instructions below.
Selecting and setting up a zone
ToselectaZoneandmodifyitssettings:
1. Press the Menu key.
2. TurnandthenpresstheEncodertoselectSettings > Zone.
3. TurnandthenpresstheEncodertoselecttheZoneyouwishtoworkwith.
4. Use any of the following instructions to update settings for the selected Zone.
Enabled
Zones2–4canbedisabledifrequired.Thisisuseful,forexample,ifonlytwoZones
have been set up, as disabled Zones are not displayed in any screens when setting
levels.
To enable or disable the selected Zone:
a. Select the Enabled menu item.
b. PresstheEncodertoenable()ordisable()theselectedZone.
c. Press any key to exit
Menu key
Rotary
Encoder
MS-IP700iorMS-AV700i
