• Contact your FUSION dealer or send an email to FUSION
from www.fusionentertainment.com.
My Apple device has gone into thermal protection
mode
NOTICE
The temperature of the internal dock in the stereo is slightly
higher than the ambient temperature outside the stereo. The
Apple device shuts down when the operating temperature is
exceeded. In addition, using the Apple device in a low charged
state increases the heat generated while it is charging. For more
information, go to www.apple.com.
• Carefully remove the Apple device from the stereo and allow
it to cool down before using it again.
• When the Apple device is low on battery charge, charge the
Apple device.
My MTP device is unresponsive
For best results, the music folders on an MTP device should not
contain more than 300 files each. Exceeding 300 files per folder
can cause the Android device to become unresponsive and
reset the connection to the device.
NOTE: Different operating systems and media players provide
different levels of support for MTP. Refer to
www.fusionentertainment.com for device compatibility
information.
The stereo does not find all of my music files on my
MTP device
Music files must be located in a folder using one of these
names. The folder must be located in the root directory of the
media player.
• My Music
• My_Music
• mobile
• Music
My Bluetooth audio is interrupted by short breaks
• Ensure the media player is not covered or obstructed.
Bluetooth technology performs best with line-of-sight
operation.
• Bring the media player within 10 m (33 ft.) of the stereo.
• Turn off the Discoverable setting after pairing a Bluetooth
device to the stereo.
The stereo does not display all song information from
my Bluetooth source
The availability of song information such as song title, artist
name, track duration, and album cover artwork depends on the
capability of the media player and music application.
Album cover artwork and shuffle and repeat status icons are not
supported by Bluetooth technology.
Specifications
General
Weight 0.88 kg (1.96 lb.)
Water resistance IEC 60529 IPX5
Operating temperature range From -5 to 50°C (from 23 to 122°F)
Storage temperature range From -20 to 70°C (from -4 to 158°F)
Compass-safe distance 15 cm (5.9 in.)
Input voltage From 10.8 to 16 Vdc
NMEA 2000 LEN 1 (50 mA)
Bluetooth Class 2
Bluetooth/ANT frequency From 2,400 to 2,483.5 MHz
Bluetooth/ANT power (max.) 8 dBm EIRP
On-board, Class D Amplifier
Output music power per channel 70 W max. x 4 at 2 ohms
Total output music power 280 W max.
Output power per channel
(14.4 VDC at 10% THD+N)
43W RMS x 4 @ 2 ohms
26W RMS x 4 @ 4 ohms
Line output level (max.) 6 V (peak to peak)
Aux input level (typical) 1 V RMS
Current Consumption
Stereo is off Ignition off Standby Mode = Off < 3 mA
Standby Mode = On < 200 mA
Ignition on Standby Mode = Off < 20 mA
Standby Mode = On < 200 mA
Stereo is on Muted <900 mA
Typical listening volume 2 A
Maximum current draw 15 A
Tuner Europe and
Australasia
USA Japan
FM radio
frequency range
87.5 to 108 MHz 87.5 to
107.9 MHz
76 to 95 MHz
FM frequency
step
50 kHz 200 kHz 50 kHz
AM radio
frequency range
522 to 1620 kHz 530 to
1710 kHz
522 to
1620 kHz
AM frequency
step
9 kHz 10 kHz 9 kHz
10 Appendix
