FUTABA GV-1 User Manual

1414
1414
14
BEFORE USE
1
2
3
OF
F
O
N
OF
F
1
3
OF
F
2
3
Examples
The GV-1 functions can be selected to match the transmitter used.
Select the functions by referring to the examples shown below.
Function
Speed
switching
Governor
on/off
Mixture
function
Connection
Example 1
Three
positions
ON/OFF
None
Throttle servo
Not connected
CH7(example)
CH8(example)
When used with PCM1024Z
2P switch channel
3P switch channel
Throttle channel
Sx
Rx
Sx
Rx
Sx
Rx
Example 2
Speed
switching
position 1
used
None
Throttle servo
Not connected
Two positions
CH7(example)
When used with FF8 or PCM1024Z
(without mixture function)
Not connected
3P switch channel
Throttle channel
Example 3
Speed
switching
position 1
used
Throttle servo
Mixture servo
Two positions
CH7(example)
Mixture
control used
Volume channel
3P switch channel
Throttle channel
When used with FF8 or PCM1024Z
(with mixture function)
