1010
1010
10
BEFORE USE
SENSOR
THRO MXTR
r.p.m 1 r.p.m 2 r.p.m 3
m.trim GOV on GOV off
on / off
Tx
GV-1
& Sx
SENS.
r.p.m THRO
m.trim
BEFORE USE
Set contents
Immediately upon opening the carton, check if the following items are sup-
plied.
Miniature screwdriver
GV-1 control amp
GV-1 magnetic sensor
Magnet
Sensor mounting stay
For 30 engine
For 60 engine
Seal
Sensor mounting screws
