FUNCTIONS
Speed setting rS1~rS3
The speed can be set for three points.
Connect the speed setting input "AUX(r.p.m)" to a receiver vacant channel.
(Set value check)
1Operate the switch (3-position), or
variable resistor knob.
The set values are displayed on the LCD screen in rS1->rS2-
>rS3 (slow->medium->high) order.
(Speed setting method)
1Set the switch or variable resistor knob to the de-
sired position and set the speed of that point by
pressing the DATA+ key (accelerate) or DATA-
key (decelerate).
-When not using the speed setting channel, set rS2 only.
rS1 and rS3 are disabled.
-When using a 2-position switch, set rS1 and rS3 only. rS2 is
set to the initial value (1500rpm).
(Setting range) 1000~2100rpm
(Initial value) rS1:1300rpm rS2:1500rpm rS3:1700rpm
Reference
If the speed is set to 1000rpm or less, the display will change to "-Off-" and
the governor can be turned off at that switch position.
The engine and rotor displays can be switched with the "[speed display
mode" set-up screen.
