FUNCTIONS
Limit set Lmt
This function sets the governor control range.
When using the governor for the first time, and when the
servo throw was changed, always perform limit setting
again.
(Limit setting method)
1When"Idle" is flashing, set the
throttle stick to the maximum slow
position and press the DATA+ or
DATA- key.
About 1 second later, "High" begins to flash.
2When"High" is flashing, move the
throttle stick to the full high posi-
tion and press the DATA+ or
DATA- key.
About 1 second later, "Stop" begins to flash.
3When"Stop" is blinking, move the
throttle stick and cut switch to the
engine cut position and press a
DATA (+ or -) key.
This completes idle/high/stop point setting.
(Initial values) Low:1930us High:1110uS Stop:2070uS
