ADJUSTMENTS AND FLIGHT TECHNIQUES
Master and Slave Channel Selection
In the first example shown, THR (Throttle) is set at "mas". The Master channel can be changed by pressing
the or
program key.
or
cursor key and the Slave channel
The cursor can be moved to the "slv" position with the
selected by pressing the or
program key.
Master Channel Setting
1) Select the PROG-MIX screen as described on
page 22.
2) Select the CHANNEL SETTING screen
by
pressing the SET program key.
3) The Master channel can be set
by pressing the
or program key to change the
Combination of Mixing Circuits
Programmable mixing circuits can be combined
with each other, or with built-in mixing circuits
by two methods.
1) Setting a Mixing Circuit No. in the "mas"
position (MX1, MX2, MX3, or MX4).
2) and setting.
channel.
selected
by moving
the
cursor
with
the
or cursor key.
or cursor key.
2) Select the
Slave
channel
with
the or
4) The mixinq circuit to be programmed can be
Mixing Number Method
Depending upon which channels are selected on
different mixing circuits, MX1, MX2, MX3, or
MX4 can be displayed in the "mas" position. The
slave channel of the mixing number displayed in
the "mas" column, then.becomes a Master chan-
nel on the mixing circuit line that it is displayed
and the two circuits are connected.
1) Move the cursor to the "slv" position with the
proqram key. In the example above, the Slave
channel on (Mixing Circuit No. 1) is set
to
AIL.
[24]
