FUTABA PCM1024H - Set Contents; Ratings

•SET CONTENTS
Model
Transmitter
Receiver
Servos
Switch
Nicd Battery
Misc.
PP-9VHP
FP-T9VHP x 1
FP-R-129DPx 1
FP-S9201 x 5
SSW-J x 1
NR-4LBx 1
Battery charger, extension cord, DSC cord, CHG adaptor, DSC-CHG cord,
frequency flag, spare output arms, neck strap, screws
•RATINGS
Transmitter FP-T9VHP Servo FP-S9201
Operating System : Two-stick, 9 Channel, PCM
Transmitting Frequency: 72MHz CH.12— CH.56,
53MHz, and 50MHz
Modulation : FM-PCM/PPM selectable.
Power Requirement : 9.6 volt (8/500mAH) internal
Nicd battery
Current Drain : 230mA
Receiver FP-R-129DP
Control System + pulse width control
1520)iS neutral
Operating Angle Each direction from neutral —
45° or greater (including trim)
Power Requirement 4.8 volt Nicd battery (shared
w/receiver)
Current Drain 8mA at 4.8V (at idle)
Output Torque 5 kg-cm (69.5 oz.-in.)
Operating Speed 0.22 sec/60°
Dimensions 40.5 x 20 x 35.5mm
Weight 50g(1.8oz.)
Receiving Frequencies 72MHz, 53MHz, and 50MHz
Intermediate Frequency 1st IF : 10.7MHz
2nd IF:455kHz
Power Requirement 4.8 volt Nicd battery (shared
w/servos)
Current Drain 35mA (4.8V reception)
Dimensions 60.3x37.8x24.1mm
Weight 45g(1.6oz.)
Receiving Range 500m (1,500 ft.) ground
1,000m (3,000ft.) air
(When FP-T9VHP used under
best radiowave conditions)
Voltage : 4.8V 1,000mA
Dimensions : 56 x 67 x 14.8mm
Weight : 1 20g (4.2 oz.)
Receiver and Servo Nicd Battery Pack NR-4LB
Charger FBC-6B (2)
Input Voltage : 1 20VAC, 60Hz, 4W
Output Voltage : TX side 9.6V, 50mA
RXside 4.8V. 100mA
(Specifications are subject to change without prior notice.)
