FUTABA PCM1024H User Manual

5 servos
supplied as
standard
Servo Neutral Trimmer
(rudder servo for
helicopter)
(This trimmer is
operative even when
the gyro control box
power switch is
turned OFF.)
Gyro output
reversing switch
Gyro
sensitivity
adjustment
trimmers
Gyro
Gyro Control Box
Jumper Connector
Connector for 6V pack of five batteries
Motor Regulator Power Supply
(Insert the jumper connector when
power supply shared w/ RX.)
Control Amplifier
Gear
(Rate Gyro
Output Switching)
Extension
cord
Aileron
Servo
Elevator Servo
Throttle Servo
Rudder (Tail rotor)
Servo
Pitch Servo
(Collective)
Pay careful
attention to connector polarity
