FUTABA T26SZ - Page 72

72
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
ŶƜƖƗƈƐŃƗƜƓƈ
System mode setting, Receiver link
●
Select [System type] in the Linkage menu
and access the setup screen shown
below.
P.34
ůƌƑƎƌƑƊŃƐƈƗƋƒƇŃ
Cases when linking is necessary:
・
When using a receiver other than the initial setting.
・
When the communication system was changed.
(FASSTest18CH
↔
FASSTest12CH etc.
)
・
When a new model was created by model
selection.
●
Return to
Linkage
menu
1XPEHURIUHFHLYHUVWROLQN
Single →
FASSTest26CH, FASSTest18CH,
FASSTest12CH, T-FHSS AIR, S-FHSS
Dual →
FASSTest26CH, FASSTest18CH
Triple →
FASSTest26CH
6\VWHP7\SHVHOHFWLRQ
The T26SZ is for 2.4 GHz only. The system can be
changed from among 5 choices: FASSTest 26CH,
FASSTest18CH, FASSTest12CH, T-FHSS AIR,
S-FHSS. It is FASSTest26/18CH and FASSTest12CH
which can be chosen by R7208SB or R7308SB set.
*If you change the System type, other model data is not reset.
*After any change, remember to test the model and fully check
servo direction and motion.
*Analog servos cannot be used with the R7208SB or R7308SB
in the FASSTest12CH mode.
5HFHLYHUOLQNLQJ
The receiver will only be controlled (without being
D൵HFWHGE\RWKHUWUDQVPLWWHUVE\WKHWUDQVPLWWHULW
is linked to. When using a receiver other than one
purchased as a set, linking is necessary.
Moreover, a re-link is required when a new model
is added by model selection, and at the time of
system type change.
%DWWHU\IDLOVDIHYROWDJHVHWXS6)+66
FDQQRWEHVHW
The voltage at which battery fail-safe
activates can be set when you link. (3.5-
8.4 V) The receiver memorizes the setting
as it was at link.
Since power consumption varies with
battery type, servos and condition, please
select the fail-safe activation voltage for
your own model.
2/2 Next page
The T26SZ’s system can be changed to match
the receiver system used. The system type also
performs transmitter and receiver links, telemetry
ACT/INH, and battery F/S voltage.
