OPERATION
After you connected the effect to the mains, the EVO-3 starts running. During the Reset, the motors are
trimmed and the device is ready for use within approximately 20 seconds.
Turn the objective-lens for adjusting the focus in order to obtain a sharp projection.
Stand Alone operation
In the Stand Alone mode, the EVO-3 can be used without controller. You can do without a controller as the
EVO-3 features a built-in microphone, which provides automatic sound control.
Disconnect the EVO-3 from the controller. The lamp is automatically ignited as soon as the condensor
microphone receives music signals.
Master/Slave-operation
Connect the master and slave-devices as desribed above and set the DIP-switches accordingly.
Mic Sensitivity-/Channel Value-selector
1. Put the Dip-switch in the Sound mode and adjust the sensitivity of the activated sound by turning the Mic
Sensitivity-/Channel Value-selector.
3. In the Master mode you can select the different channels and adjust the value with the Mic Sensitivity-/
Channel Value-selector.
DMX-controlled operation
You can control the projectors individually via your DMX-controller. Every DMX-channel has a different
occupation with different features.
DMX-protocol
Control channel 1 - Rotating fibre optic module
Decimal Hexad. Percentage S/F Feature
0 7 00 07 0% 3% S No rotation
8 119 08 77 3% 47% F Forwards fibre optic effect with decreasing speed
120 131 78 83 47% 51% S No rotation
132 255 84 FF 52% 100% F Backwards fibre optic effect with increasing speed
Control channel 2 – Colour-wheel
Decimal Hexad. Percentage S/F Feature
0 127 00 7F 0% 50% F Color indexing
128 187 80 BB 50% 73% F Forwards rainbow effect with decreasing speed
188 193 BC C1 74% 76% S No rotation
194 255 C2 FF 76% 100% F Backwards rainbow effect with increasing speed
Control-channel 3 - Shutter, strobe
Decimal Hexad. Percentage S/F Feature
0 31 00 1F 0% 12% S Shutter closed
32 63 20 3F 13% 25% S Dimmer (closed to open)
64 95 40 5F 25% 37% F Strobe-effect with increasing speed
96 127 60 7F 38% 50% S No function (shutter open)
128 159 80 9F 50% 62% F Pulse-effect in sequences
160 191 A0 BF 63% 75% S No function (shutter open)
192 223 C0 DF 75% 87% F Random strobe-effect with increasing speed
224 255 E0 FF 88% 100% S No function (shutter open)
