Operators and Technicians Manual
© 2006 – 2007 FutureLogic, Incorporated. All Rights Reserved. MNL Page 16 of 29 12/06/2007
MNL-000030 REV.X07
Appendix B Paper Specifications
This appendix provides information on the paper used in the printer. For authorized ticket
converters and complete paper specifications, contact your sales representative or visit our Web
site:
www.futurelogic-inc.com.
Note: Use only approved paper in the printer. Use of improper paper may cause
damage to the device and will void the printer’s warranty.
Nominal paper thickness: 4.5mil
Paper dimensions: 65mm x 156mm (width dimension +
1mm
Ticket Stack
Ticket, 300STK, 65X156, 5M, Fanfold
Ticket, 600STK, 65X156, 5M, Fanfold
Ticket, 900STK, 65X156, 5M, Fanfold
Note: Paper width is +0mm, –1mm.
Figure B-1 Ticket Dimensional Specification
