G-U ELTRAL KS 30/40 RADIO CONTROL User Manual

4
Chain drive
Installation and Operating instructions
ELTRAL KS30/40 RADIO CONTROL
3 Intended use
The ELTRAL KS 30/40 RADIO CONTROL chain drive is designed exclusively for opening and
closing Tilt-Only windows, Top-Hung windows, Turn-Only windows, skylights, Horizontal-Pivot
and Vertical-Pivot windows.
Other use is considered inappropriate.
Gretsch-Unitas GmbH Baubeschläge accepts no liability for damage arising from inappropriate
use.
In the case of inappropriate use, the guarantee is null and void.
Our General Terms and Conditions apply.
4 Product description
The ELTRAL KS 30/40 RADIO CONTROL chain drive is designed for use in dry rooms at a
maximum permissible ambient temperature of -5° C to +65° C.
It can be installed either horizontally or vertically.
An ELTRAL KS 30/40 RADIO CONTROL set consists of:
 Chain drive with connecting cable, length 2 m
 Standard pivot bracket with spacer
 Pivot bracket for Top-Hung sash with drive mounted to the frame
 Chain holding bracket for installation on frame
 Chain holder for installation on sash
 Package with locking piece and connecting pin
 Drilling template
 Installation and Operating instructions
NOTE Spacer


The purpose of the spacer is to ensure correct positioning.
It can be removed afterwards.
The following installation variants are possible:
 attached to the frame,
 attached to the sash.
NOTE Type label


The type label is attached to the motor. With the motor installed, the type
label is not visible.
