7
10.2016 | G28706 | Designed in Germany
6 Preparing to install
DANGER
Incorrect use may cause injury to people and damage to
property
Using the type label on the motor and the data listed in chapter
"5 Technical data (1 motor)" on page 5, make sure that you have the
right motor for your installation situation.
Examine the delivered equipment immediately upon receipt and check it for possible
transport damage. Do not install the motor if it is damaged.
NOTE
With Tilt-Only sashes, the distance between the inner faces of the frame
and sash must be at least 1 mm to provide for safe closing (see depiction
below).
With fl ush windows, or if the inner face of the sash is set back from the
face of the frame, shims of the corresponding size must be inserted
between bracket of the Tilt-Only sash and sash profi le.
