2.- INSTALLATION INSTRUCTIONS
- Open the package and check that it is the correct model and it is in good condition.
- To obtain optimum performances it is necessary to maintain a minimum clearance of 50 cm between the panel heater and any
inflammable material as furniture, curtains etc.
- The studs and screws to attach the supports are in the accessories bag.
- Fix the two square brackets to the back of the heater by using the two smalls screws. (see Fig.1)
- Position and fix the top bracket at the correct distance from the floor (see Fig.2) and hang the unit on the hooks of the top
bracket.
- Mark the fixing points on the wall using a pencil. Use the heater fixing holes as a template and mark the wall through the two
fixing holes in the square brackets. Fix the heater to the wall.
