FUNCTION PANEL
6
A. Shows chamber temperature during a cycle. Unit: °C degrees
B. Shows chamber pressure during a cycle. Unit: kPa
C. Shows sterilizer period of the cycle, length and warnings.
In case of anomalies, the corresponding error code will be shown here.
(See User manual, appendix 2, page 42).
D. Lighting signals panel:
E. sterilization programs.
F. Graphics of sterilization cycle trend.
FUNCTION BUTTONS
E F G
A
B
C
D
button for the choice of
sterilization programs
button for the choice
of test programs
button to confirm
the starting of the cycle
