2.2 Manual-Mechanical Operation
The irrigation valve can be opened and closed
independent of the controller's operation.
Manual operation is useful when immediate
irrigation is required, and the controller is not
assembled yet.
The valve lever is located under the solenoid.
Remember! For controller operated irrigation, the
valve lever must be in the middle (AUTO) position.
2.3 Battery Installation
Open the battery compartment cover.
Insert 9V batteries (see illustration). All
the controller display elements appear
briefly on the display, followed by a
blinking time of 12:00. The controller is
now ready to be programmed.
Important!
Make sure to replace the battery
compartment cover with the grip (see
drawing) and then rotate the cover 1/8 of
a turn to the right.Be sure to do so
otherwise the battery cover pins might
break.
close
closed
mechanical
operation
lever
AUTO
Water Flow Direction
Manual
Operation
