Gallagher S20 User Manual

Step 4. Connect Earth and Fence leads to fence
Earthing for Step 3 (a. b. c.) Earthing for Step 3 (d.)
a) Connect green terminal to the earth rod inserted at least 2 ft (60cm) into the ground.
b) Connect red terminal to fence line.
Important: For Step 3d. ONLY, the earth lead can be connected to the earth screw on
the back of the energizer which is touching the earth rod.
d.
.
Ø0-22mm
2.

2
60cm
60cm

ENG
