Gallo Tech GStarter I - Page 10

© Copyright
Gallo Technologies
. All Right Reserved
-
10
-
52008
Figure 6
Figure
7
7 Pin Wire
Harne
ss
(
Parking Lights, Siren, Foot Brake and Door Trigger
Circuit)
Note
:
connect
C3: Red
, C3: Pink
and
C3: BLACK
wires
for stand alone “Engine Start” only configuration.
Connect all wires when installing “Engine Start
with
Alarm” configuration.
See Fig. 8.
*
C3: RED fused wire
–
+ 12v Constant Battery Input
(Module Supply Power)
. This connection should always
have +12v available
(
BAT
terminal on ignition switch or equivalent)
.
Solder connect the RED wire.
C3: YELLOW
–
Parking Light +12v output. 3Amps max.
Solder connect
one of the YELLOW wires to the
vehicle’s parking light relay.
If parking lights require more than 3 amps use an external
10 Amp
relay.
C3: ORANGE
–
Siren +12v Output.
Connect to
the RED
Siren input
wire
. Connect the second siren input (BLA
CK
wire
)
to a good chassis ground.
*
C3: PINK
–
Ignition ON +12v Input for Active Arm Lock/unlock trigger.
Connect to
IGN
1
on ignition switch.
(+12v in
ON
and
START
position and
0 v
in
OFF
and
ACC
position.)
C3: BLACK/WHITE
–
Neg.
(
-
)
Door Trigger switc
h Input.
Connect the
BLACK/WHITE wire
to the Neg. (
-
) Door
Trigger switch.
If
vehicle
has “+” Pos Door Trigger input use an external relay as shown
in
Fig. 8
.
C3: GRAY/RED
-
+12v Foot Brake Switch Input Used for Active Arm door lock input.
Connect to Foo
t brake
switch terminal that has +12v only when foot brake is depressed.
*
C3: BLACK
–
Neg.
(
-
)
Ground
Connection
Connect the BLACK wire to a good chassis ground in a convenient location.
Installing Connector
C3:
