ENGINE CRANKS BUT WILL NOT START:
Check Ignition switch wiring. The
wire must not be cut. The only
Input +12 v from connector
separate ignition wires for the vehicle’s ignition system to function properly. Make sure both of
these ignition wires have not been cut.
ENGINE STARTS IN DRIVE OR REVERSE GEAR (AUTOMATIC TRANSMISSION).
Check the location of ORANGE (Key Start Input) and B
LUE (Start Engine Output) wires. They MUST be
connected to the vehicles start wire close to the ignition switch, making certain that the Park/Neutral
AN ACCESSORY (RADIO, HEATER
ETC.) DOES NOT TURN OFF DURING ENGINE
ND/OR TURN BACK ON AFTER CRANKING:
ays have not been connected to the correct Ignition switch wires. There are usually only
two positions on the ignition switch which disconnect power to the accessories during engine
cranking. Check the specific
wiring diagrams for your Make, Model,
RED +12v from R1/R2 relay pair. It must be connected to the BLUE (Start Engine
Output) C1: wire. Also check the BLACK R1/R2 wire making certain that it is connected to a good
Check the 10 Amp fuse. If it is blown then there must be a short somewhere along the RED R1/R2
DOORS LOCK/UNLOCK WHEN THEY SHOULD UNLOCK/LOCK:
Connector C2: 6 Pin Wire Harness wires have been incorrectly connected to the vehicles Master Lock
