Gallo Tech GStarter I - Remote Key FOB Operation

© Copyright
Gallo Technologies
. All Right Reserved
-
3
-
52008

Data bus
Systems 2003
and newer
GM Trucks
/
SUV’s, ‘96
-
04 Jeep Grand Cherokee
Data bus
systems send low current “Data messages” to the door lock controllers on a network in order to
lock a
nd unlock the vehicle. To install aftermarket systems in these vehicles, an interface module is required
that converts the regular lock/unlock pulses into “Data messages” to allow locking & unlocking.
T
his type
system requires that you have a good working
knowledge
of
their operation
before
attempting
installation of
alarm functions.
“Engine Start” only function can be easily installed.
(Lock Button): Arm/Remot
e
-
Lock/Panic/Siren
-
Stop
a.)
A
rms the
s
ystem
and locks the doors
with one press

Siren will
c
hirp once and parking lights flash once
.
The
blue LED on the Engine Start button will flash
slowly.

The
alarm
will chirp and parking lights will flash 3 times if
all
the doors are not closed during arming.
You must wait 3
seconds after closing all
the
doo
rs
before
the arm button can be pressed to arm the
system.

If the alarm siren has been triggered, pressing this button one time will
silence
the siren and keep
the
system
in the
armed
mode.
b.)
Panic:

When ignition switch is
OFF
, holding this button for over 2
seconds will cause the siren to sound for
30 seconds and the system will remain in the
armed
mode.
c.)
Lock only
(when vehicle occupied)

When the ignition key is in the
ON
position, and the system is
dis
armed
, pressing this button will
lock the doors. The sys
tem will stay in the
disarmed
mode
.
.
(
Unlock Button): Disarm/Remote
-
Unlock/Releas
e
-
Anti
-
hijack.
a.)
D
isarm the system
and unlock the doors
with one press

Siren will chirp twice and the parking lights will flash twice. The green LED on the Engine Start
but
ton will flash rapidly. The doors will unlock and the system will be in the
disarmed
mode.

Within 30 seconds after pressing the button, if a door is not opened or the ignition key is not turned
to the
ON
position, the system will automatically
re
arm and
re
lock the doors.

If the system has been triggered while in the
armed
mode, the siren will chirp and the parking lights
will flash four times, when the unlock button is pressed.
b.)
Unlock
o
nly
(when vehicle occupied)

When the ignition key is in the
ON
position,
and the system is
disarmed
, pressing this button will
un
lock the doors. The system will stay in the
disarmed
mode.
c.)
Release
A
nti
-
H
ijack:

When the alarm system is in the anti
-
hijack mode, pressing this button will release the anti
-
hijacking
mode.
Mute Butt
on: Mute
-
(A
rm
/
Disarm)/Remot
e
-
Lock/Siren
-
Stop
a.)
Mute Arm:

When in
disarmed
mode press
one time,
p
arking lights flash once, Blue L.E.D.
on the Engine Start
button will
flash slowly,
the siren will not chirp, the
doors will lock and system will be in
armed
mo
de. If a
door is not closed when pushing the
button, the siren will chirp and the parking lights will flash 3
times and
the system will stay in the
armed
mode. When the door is closed the system will be in the
armed
mode.

Siren stop: When the alarm siren
is triggered
, pressing the
button
or the
button
will stop the
siren sounding and the system will stay in the
armed
mode. Pressing the
button will disarm the
system
and unlock the doors
.
b.)
Mute
D
isarm:

When in the
armed
mode, press
one time then pre
ss
will mute the disarm siren.
1.2 REMOTE
KEY
FOB OPERATION:
