To complete installation, the motor must be provided with a couple of
adaptors (corresponding with the tube) and a fixing bracket. For a list of the
available accessories, refer to the catalogue.
WARNING: incorrect installation can cause serious injuries. Follow
the installation instructions. Before you remove all unnecessary
cables and turn off any equipment not required for this operation.
1
Fix the adaptors to the motor distinguishing the limits ring from
the drive pulley
.
A
B
2
Insert the motor into the tube until its end stops against the
limits ring.
E
F
INSTALLATION
