GAPOSA XQ40 - Setting the Limits

IMPORTANT:
•Motors are supplied with pre-set limit switches, in order to
allow two turns in both directions.
•Limit-switches setting procedures shown are valid for right and
left side installation.
•Always set the UP limit switch FIRST
SETTING THE LIMITS
SETTING WITH PUSHBUTTON TOOL
ACPRE/ACPRET (optional)
CHOOSE AN OPTION
SETTING WITH STANDARD PUSHBUTTON
[only for XQ50]
OPTION 1.
Shutter with
mechanical stops or
cassette awnings
OPTION 3.
Shutter with
mechanical stops or
cassette awnings
OPTION 2.
Shutter or awnings
without stops
OPTION 4.
Shutter or awnings
without stops
