l For a 2-door JK hard top, extend the length of the assembly so that 14 holes of
part A are exposed from part B.
NOTICE
Other hard top models will need custom installation.
2. Insert two Short Quick Release Pins (G) into the first and last overlapping holes.
Where part A extends out of part B will become the rear of the lifting frame.
3. Repeat steps 1 and 2 to put together the second Length Adjuster Assembly.
4. Insert the Wide Width Adjusters (C) through the rectangular slots at the front and
rear of each Length Adjuster Assembly with the open end facing up.
5. Align each hole in part C with the center of each Length Adjuster Assembly.
