Each carabiner should be 15 inches from the MyLifter cable and each should
align with one of the pulley marks.
Installing the MyLifter units on the same Smart
Track
NOTICE
If your studs run perpendicular to your garage door, you will need to install both
MyLifter units on the same Smart Track with the cables facing toward the opposite
Smart Track.
1. Install each lifter on the Smart Track aligning the cables with the pulley marks
and using the four Long Quick Release Pins.
Make sure the pins go all the way through the holes in the MyLifter brackets and
the Smart Track. There should be three open holes between the MyLifter units
on the Smart Track.
2. Place the carabiners on the far side of the opposite Smart Track in the holes dir-
ectly across from the lifter cables.
