ELECTRIC CONVECTION OVENS
EN
1 - First Part
1.4 - Technical specifications and rating plate
Cod.
Id. n°
Mod.
Id. n°
KW
10/04/26
IT09120000006460
MADE IN ITALY
pict. 1
Model 523 M-A-D 5 M-A-D 4 M-A-D
Power
3500 W 7000 W 7000 W
Power supply
230V~;50/60 Hz
400V~ 3N; 50/60
Hz
400V~ 3N; 50/60
Hz
Electrical
connection
type "X" type "X" type "X"
Weight
56 Kg 82 Kg 82 Kg
Dimensions
(mm)
635x750x690 965x830x615 965x830x615
Capacity
N°5 trays
2
/
3 GN
N°4 trays
1
/
1 GN
N°4 trays
600 x 400 mm
Distance
between trays
75 mm 75 mm 80 mm
Max. food load
6kg per shelf (total weight of food+pan)
Wiring type
H07RN-F
3 x 2.5 mm2
H07RN-F
3x4 mm²/5 x 2.5
mm2
H07RN-F
3x4 mm²/5 x 2.5
mm2
Water inlet
¾" G ¾" G ¾" G
Water hardness
Max 3° F Max 3° F Max 3° F
Water pressure
150-300kPa 150-300kPa 150-300kPa
IP rating
IPX0 IPX0 IPX0
Mounting
On bench or stand
