ELECTRIC CONVECTION OVENS
EN
IT
1 - First Part
1.4 - Technical specifications and rating plate
Model 7 M-A-D 6 M-A-D
Power
9400 W 9400 W
Power supply
400V~(3N);
50/60 Hz
400V~(3N);
50/60 Hz
Electrical
connection
type "X" type "X"
Weight
102 Kg 102 Kg
Dimensions
(mm)
965x830x775 965x830x775
Capacity
N°6 trays
1
/
1 GN
N°6 trays
600 x 400 mm
Distance
between trays
75 mm 80 mm
Max. food load
6kg per shelf
(total weight of food+pan)
Wiring type
H07RN-F
3 x 2.5 mm2
H07RN-F
3 x 2.5 mm2
Water inlet
¾" G ¾" G
Water hardness
Max 3° F Max 3° F
Water pressure
150-300kPa 150-300kPa
IP rating
IPX0 IPX0
Mounting
On bench or stand
Model 12 M-A-D 10 M-A-D
Power
14100 W 14100 W
Power supply
400V~(3N);
50/60 Hz
400V~(3N);
50/60 Hz
Electrical
connection
type "X" type "X"
Weight
126 Kg 126 Kg
Dimensions
(mm)
965x830x1070 965x830x1070
Capacity
N°10 trays
1
/
1 GN
N°10 trays
600 x 400 mm
Distance
between trays
75 mm 80 mm
Max. food load
6kg per shelf
(total weight of food+pan)
Wiring type
H07RN-F
5 x 4 mm2
H07RN-F
5 x 4 mm2
Water inlet
¾" G ¾" G
Water hardness
Max 3° F Max 3° F
Water pressure
150-300kPa 150-300kPa
IP rating
IPX0 IPX0
Mounting
On bench or stand
Model 16 M-A-D 20 M-A-D
Power
24.000 W 14200 W
Power supply
400V~(3N);
50/60 Hz
400V~(3N);
50/60 Hz
Electrical
connection
type "X" type "X"
Weight
200 Kg 200 Kg
Dimensions
(mm)
1020x1850x950 1020x1850x950
Capacity
N°16
trays
600x400
mm
N°16
trays
660x460
mm
N°20 trays
1
/
1 GN
Distance
between trays
80 mm 65 mm
Max. food load
6kg per shelf
(total weight of food+pan)
Wiring type
H07RN-F
5 x 64 mm2
H07RN-F
5 x 6 mm2
Water inlet
¾" G ¾" G
Water hardness
Max 3° F Max 3° F
Water pressure
150-300kPa 150-300kPa
IP rating
IPX0 IPX0
