Garbin 6D - Analogic Control Panel Overview

42
ELECTRIC CONVECTION OVENS
EN
Temperature display Temperature display
Core probe display
Drying/humidification
display
Drying/humidification
display
Humidifi
cation
display
Drying/humidification
knob
Drying/humidification
knob
Temperature knob Temperature knob
Timer knob Timer knob
Timer display Timer display
Main switch Main switch
Core probe button Multispeed button
Core probe knob
START/STOP button
START/STOP button
3.3.1. Analogic panel control
3 - THIRD PART_Operating instructions
Humidification
knob
5-7-12-20 A523 A 4-6-10-16 A
