Gardena R50Li User Manual

3.19.6 Unsymmetrical working area with a narrow passage and a number of islands
Area 150 m
2
2 m / 7 ft
Timer 07:00 - 17:00
Monday, Tuesday,
Wednesday, Friday
Remote start - Rarely (factory setting)
Proportion
Remarks The guide wire must be placed along
the narrow passage to ensure that
the robotic lawnmower can with ease
locate the charging station from the
right hand side of the working area.
Select Proportion: Rarely as the right
hand area is a small fraction of the to-
tal area. Make sure guide wire is laid
according to recommendations in
Laying and connecting the guide wire
on page 18
3.19.7 Three areas linked with two narrow passages
Area
400 m
2
. R70Li, R80Li only.
Timer 07:00-23:00
Monday, Tuesday, Thursday, Friday
Remote start 1 - Rarely
Proportion
Remote start 2 - Rarely
Proportion
Remarks As the working area contains three
areas linked by two narrow passages,
Remote start 1 and Remote start 2
must be used to obtain an even mow-
ing result across the entire working
area. Available in R70Li, R80Li. Make
sure guide wire is laid according to
recommendations in Installation of
the guide wire on page 18
3.19.8 A secondary area
Area
200 + 50 m
2
Timer 07:00 - 18:00
Monday, Tuesday,
Thursday, Friday
Remote start - Rarely (factory setting)
Proportion
Remarks The secondary area is cut using the
MAN mode on Wednesday and Sat-
urday.
303 - 001 - 21.09.2017 Installation - 33

Gardena R50Li Specifications

General

Cutting Width	17 cm
Battery Type	Lithium-Ion
Battery Capacity	2.1 Ah
Charging Time	50 min
Maximum Slope	25%
Typical Mowing Time on One Charge	65 min
Weight	7.4 kg
Area Capacity	500 m²
