Garmin aera 795/796 Quick Reference Guide
190-01194-01 Rev. A
29
Flight Planning
Overview GPS Navigation Flight Planning Hazard Avoidance Utilities Appendix Index
3.7 APPROACHES
WARNING: The aera 795/796 is not designed to be independently used for
flight into instrument meteorological conditions (IMC) or other conditions in
which aircraft control is based solely upon flight instruments. The approaches
provided are for monitoring purposes only. Only the final course segment
(final approach fix (FAF) to missed approach point (MAP)) of the published
approach is available for monitoring.
An approach can be selected using the Direct-to, Active Flight Plan, and the Saved
Flight Plan functions.
Selecting an approach from the active or saved flight plan:
1)
From the Main Menu, touch the Active FPL Icon.
Or
:
a)
From the Main Menu, touch the FPL List Icon.
b)
Touch the desired Saved Flight Plan from the list. An option menu
appears.
c)
Touch the 'Review Flight Plan' menu option.
2)
With the flight plan displayed, touch the Menu Icon.
3)
Touch the 'Select Approach' menu option (only available if the
destination airport has a published approach). A vertical list of available
approaches is displayed.
4)
Touch the desired approach. The 'Vectors to Final?' window appears.
5)
Touch 'Yes' or 'No'. The procedure is added to the end of the flight plan.
If activating an approach from the Active Flight Plan, the aera 795/796
immediately begins to provide guidance to the first waypoint in the
approach.
Selecting an approach using the Direct-To function:
1)
Touch the Direct To Icon.
2)
Touch the Menu Icon.
3)
Touch the 'Select Approach' menu option (only available when
navigating a flight plan. A vertical list of available approaches is displayed.
4)
Touch the desired approach. The 'Vectors to Final?' window appears.
To Next Page
