Wire Label Wire Color
Wire
Gauge
Wire Function
SWITCH INPUT: CALIBRA
TION ENABLE
Black 18 AWG
Grounding this wire for 5 seconds places the device into
calibration mode. You must ground this wire again for
five seconds to exit calibration mode (Calibrating the
Tank Sensors, page 19).
SWITCH INPUT: STORE
MIN TANK VALUES
Brown 18 AWG
Ground this wire when configuring the tank sensors (Cali
brating the Tank Sensors, page 19).
SWITCH INPUT: STORE
MAX TANK VALUES
Red 18 AWG
Ground this wire when configuring the tank sensors
( (Calibrating the Tank Sensors, page 19).
SWITCH INPUT: LIVEWELL
CYCLE ADJ
Orange 18 AWG
Ground this wire when configuring the live-well pump
cycle settings (Configuring the Livewell Automatic Pump
Cycle Settings, page 20).
SWITCH INPUT: SPARE Yellow 18 AWG Unused
Navigation and Anchor Light Wiring
The first three channels on this device can be used for navigation lighting to satisfy the international regulations
for preventing collisions at sea. Depending on the navigation-lighting configuration on your boat, you can
choose from three different options for activating these lights.
NOTE: You can view examples of common wiring installations including these navigation light options on the
Garmin website. Go to garmin.com/manuals/boatswitch/.
Option A (default): One connection for red/green navigation lights, and one connection for white navigation/
anchor lights (Navigation Lights Option A, page 13).
Option B: One connection for red/green/white navigation lights, and one connection for anchor lights
(Navigation Lights Option B, page 14).
Option C: One connection for red/green/white navigation lights, one connection for steaming lights, and one
connection for anchor lights (Navigation Lights Option C, page 15).
Deactivated: The first three channels are not interconnected, and act as assignable independent switches.
These switches can still be used for lighting, but connected lights must be turned on and off independently of
one another (Configuring The Navigation Light Option, page 22).
12
