4.8 VOR/ILS INDICATOR (GNS 430 ONLY)
4.8.1 VOR/ILS Indicator Function
NOTE
Because the GNS 430 includes a “CDI” button that performs switching between GPS and
VOR/ILS on a remote indicator, it is seldom necessary to use these outputs to drive an
indicator. It is only necessary when it is desired for a separate indicator to display
VOR/ILS deviation full-time (regardless of the “CDI” button status).
The VOR/ILS indicator displays both lateral and vertical, To/From indications, lateral and vertical flags
and superflags. GNS 430 connector P4006 always outputs the VOR/Localizer/Glideslope navigation
information. The VOR/ILS pins on GNS 430 connector P4006 are used to drive an indicator that displays
VOR/ILS information at all times, regardless of the CDI selection on the GNS 430.
VOR/LOC COMPOSITE OUT is a standard VOR/Localizer Composite output signal which may be used
to drive the Left/Right, TO/FROM, and Flag indications of certain navigation indicators that contain an
internal converter.
The ILS ENERGIZE output goes low when the VLOC frequency is channeled to a localizer channel.
4.8.2 VOR/ILS Indicator Electrical Characteristics
4.8.2.1 Superflags
Pin Name Connector Pin I/O
VOR/LOC SUPERFLAG P4006 15 Out
GLIDESLOPE SUPERFLAG P4006 38 Out
The Superflag outputs supplies not less than 500 mA on a 28 volt system and 250 mA on a 14 volt system
with the output voltage not less than (AIRCRAFT POWER - 3 V
DC
) when the flag is to be OUT OF
VIEW. The output voltage with respect to ground is less than 3 V
DC
when the flag is to be IN VIEW.
4.8.2.2 Deviation
Pin Name Connector Pin I/O
VOR/LOC +LEFT P4006 5 Out
VOR/LOC +RIGHT (VOR/LOC COMMON) P4006 6 Out
GLIDESLOPE +UP P4006 32 Out
GLIDESLOPE +DOWN/-FLAG (GLIDESLOPE
COMMON)
P4006 31 Out
The Deviation outputs are each capable of driving up to three 1000 : meter loads with r150 mV
DC
r10%
with respect to 2.5V Common for full-scale deflection. The drive circuit provides for more than full-scale
deflection with a maximum course deviation output voltage of ±300 mV
DC
r10%.
4.8.2.3 TO/FROM
Pin Name Connector Pin I/O
VOR/LOC +TO P4006 1 Out
VOR/LOC +FROM (VOR/LOC COMMON) P4006 2 Out
The To/From outputs are capable of driving up to three 200 : meter loads. When indicating TO, the output
is +225 ±75 mV
DC.
When indicating FROM, output is -225 ±75 mV
DC.
When invalid information is
present (Flag IN VIEW) the TO/FROM output is 0 ±10 mV
DC.
