Garmin GPSMAP 2110 User Manual

10
INSTALLATION INSTRUCTIONS
GPSMAP 2106/2110 & GPS 17
GARMIN
GPSMAP 2106/2110
GPS 17
GARMIN
GPSMAP 2106/2110
Optional Alarm Wiring
The GPSMAP 2106/2110 has an alarm circuit that can be used with a lamp, a horn, or both to alert you when the unit displays a message. The
alarm circuit pulls low when the alarm sounds. The alarm does not have to be wired for the unit to function. The maximum current is
100 milliamps. A switch or relay can be used to select between visual and audible alerts.





+
-



100 ma
Max Coil Current




GARMIN
GPSMAP 2106/2110

Garmin GPSMAP 2110 Specifications

General

Sport (fitness, running)	No
Marine (chartplotters, sounders)	Yes
Routes quantity	50
Number of waypoints	3000
Form factor	Plug-in
Display resolution	640 x 480 pixels

Weight and Dimensions

Depth	83 mm
Width	333 mm
Height	224 mm
Weight	2270 g
