Compass: Automatically switches from an electronic compass
to a GPS compass when you are traveling at a higher rate of
speed for a period of time.
Calibrate Compass: Allows you to calibrate the compass if you
experience irregular compass behavior, for example, after
moving long distances or after extreme temperature changes
(Calibrating the Compass, page 3).
Trip Computer
The trip computer displays your current speed, average speed,
trip odometer, and other helpful statistics. You can customize
the trip computer layout, dashboard, and data fields.
Trip Computer Settings
From the trip computer, select MENU.
Reset: Resets all the trip computer values to zero. For accurate
information, reset the trip information before beginning a trip.
Change Data Fields: Customizes the trip computer data fields.
Change Dashboard: Changes the theme and information
displayed on the dashboard.
NOTE: Your customized settings are remembered by the
dashboard. Your settings are not lost when you change
profiles (Profiles, page 14).
Insert Page: Inserts an additional page of customizable data
fields.
TIP: You can use the arrow keys to scroll through the pages.
Remove Page: Removes an additional page of customizable
data fields.
More Data: Adds additional data fields to the trip computer.
Less Data: Removes data fields from the trip computer.
Restore Defaults: Restores the trip computer to factory default
settings.
Altimeter
By default, the altimeter displays the elevation over the distance
traveled. You can customize altimeter settings (Altimeter
Settings, page 4). You can select any point on the plot to view
details about that point.
Altimeter Plot Settings
From the altimeter, select MENU.
Reset: Resets the altimeter data, including waypoint, track, and
trip data.
Altimeter Setup: Access additional altimeter settings (Altimeter
Settings, page 4).
Adjust Zoom Ranges: Adjusts the zoom ranges shown on the
altimeter page.
Change Data Fields: Allows you to customize the altimeter data
fields.
Restore Defaults: Restores the altimeter to factory default
settings.
Altimeter Settings
From the altimeter, select MENU > Altimeter Setup.
Auto Calibration: Automatically calibrates the altimeter each
time the device is turned on.
Barometer Mode: Variable Elevation allows the barometer to
measure changes in elevation while you are moving. Fixed
Elevation assumes the device is stationary at a fixed
elevation, so the barometric pressure should only change
due to weather.
Pressure Trending: Sets how the device records pressure
data. Save Always records all pressure data, which can be
helpful when you are watching for pressure fronts.
Plot Type: Records elevation changes over a period of time or
distance, records barometric pressure over a period of time,
or records ambient pressure changes over a period of time.
Calibrate Altimeter: Allows you to manually calibrate the
barometric altimeter (Calibrating the Barometric Altimeter,
page 4).
Calibrating the Barometric Altimeter
You can manually calibrate the barometric altimeter if you know
the correct elevation or the correct barometric pressure.
1
Go to a location where the elevation or barometric pressure
is known.
2
From the altimeter, select MENU.
3
Select Altimeter Setup > Calibrate Altimeter.
4
Select Method to select the measurement to use in
calibration.
5
Enter the measurement.
6
Select Calibrate.
Navigation
Navigating to a Destination
1
Select FIND.
2
Select a category.
3
Select a destination.
4
Select Go.
Your route appears as a magenta line on the map.
5
Navigate using the map (Navigating with the Map, page 4)
or compass (Navigating with the Compass, page 4).
Navigating with the Map
1
Begin navigating to a destination (Navigating to a
Destination, page 4).
2
Select Map.
A blue triangle represents your location on the map. As you
travel, the blue triangle moves and displays your path.
3
Complete one or more actions:
• To view different areas of the map, select , , , or .
• To zoom in and out of the map, select and .
Navigating with the Compass
When navigating to a destination, points to your destination,
regardless of the direction you are moving.
1
Begin navigating to a destination (Navigating to a
Destination, page 4).
2
Select Compass.
3
Turn until points toward the top of the compass, and
continue moving in that direction to the destination.
Stopping Navigation
Select FIND > Stop Navigation.
Waypoints
Waypoints are locations you record and store in the device.
Waypoints can mark where you are, where you are going, or
where you have been. You can add details about the location,
such as name, elevation, and depth.
You can add a .gpx file that contains waypoints by transferring
the file to the GPX folder (Transferring Files to Your Device,
page 15).
Creating a Waypoint
You can save your current location as a waypoint.
1
Select MARK.
4 Navigation
