190-01499-02 GTX 3X5 Transponder TSO Installation Manual
Rev. 9 Page A-7
Data Formats
EFIS Air Data
Table A-4 EFIS Air Data
Flight Control
Table A-5 Flight Control
Label Data Transmission Rate
Periodic
Timeout
100 Selected Course #1 250 ms 250 ms
102 Selected Altitude 800 ms 800 ms
164 Radio Height 250 ms 250 ms
203 Altitude 250 ms 250 ms
204 Baro-Corrected Altitude #1 250 ms 250 ms
205 Mach 500 ms 500 ms
206 Indicated Airspeed 500 ms 500 ms
210 True Airspeed 50 ms 50 ms
211 Total Air Temperature 2000 ms 2000 ms
212 Altitude Rate 250 ms 250 ms
213 Static Air Temperature 2000 ms 2000 ms
234 Baro Setting (hPa) 500 ms 500 ms
235 Baro Setting (in Hg) 500 ms 500 ms
306 Joystick Waypoint Latitude 500 ms 500 ms
307 Joystick Waypoint Longitude 500 ms 500 ms
314 True Heading 200 ms 200 ms
320 Magnetic Heading 200 ms 200 ms
325 Roll Angle 200 ms 200 ms
Label Data Transmission Rate
Periodic
Timeout
102 Selected Altitude 200 ms 800 ms
234 Baro Setting (hPa) 125 ms 500 ms
235 Baro Setting (in Hg) 125 ms 500 ms
271
Pitch Discrete Data, Bendix/
King KFC 225
125 ms 500 ms
