Page 13
Periodic Maintenance (Every 10,000 cycles)
N
NOTE: BEFORE PERFORMING ANY MAINTENANCE ON THE PD-5, TURN THE UNIT OFF
AND UNPLUG THE POWER CORD FRO
M THE ELECTRICAL OUTLET.
Greasing the Drive Shaft
Remove the left side of the PD-5 by removing 11 screws with a T-20 torx driver. Locate the knurled brass knob
and rotate ½ turn clockwise. This will automatically apply grease to the drive shaft.
Greasing the Vertical Crusher Slide Rails
Lift the door and apply a small coat of white lithium grease on each vertical crusher slide rail with a Q-tip. Spread
until a thin layer of grease coats the entire rail. Repeat on each of the four rails.
