When ordering spare parts, for positive identi.
tation of your unit please quote all the infor
mation printad on the paper label underneath
the unit plate or on the outside of the packing
carton, also the part rumbar if listed and the
Colour, or voltage and power supply frequency
where appropriate,
Please address service and sparos encuirios to
your dealer or, in case of difficulty, to the
Garrard agent in your country.
The address of the Garrard Sales Servi
Department in the United Kingdom is Kembrey
Street, Swindon, Wiltshire SN2 6BP, England.
Their telephone number is Swindon (0793)
03471
AL US.A. enquiries to:
PLESSEY CONSUMER PRODUCTS,
GARRARD DEALER SALES DIVISION,
100 COMMERCIAL STREET,
PLAINVIEW, NEW YORK 11809,
SELECTED SPARE PARTS LIST
Description of Part Part Number
Automatic Record Spindle 72040
Single Record Spingle 75196
Large Contre Hole Record Adaptor 72698
Tonearm Counterbalance Weight 5138
Sligein Cartridge Carrier, Type C3... 75149
Kit of parts to fox Pickup Cartridge 59048091
Setting Gauge for Cartridge 75291
Platter Retaining Clip 43857
Platter complete with Mat 75190
(slate power supply frequency)
Stroboscepe Ring for Platter (69Hz) ... 75101
Stroboscape Ring for Platter (S0Hz) 75445,
Intermediate Wheel 78625
Damping Pad tor mounting spring 71084
Synchronous Motor (stato voltage) 60810,
Motor Pulley (GHz) with Extractor 60902
Motor Pulley (SOHz) with Extracter 60903,
Neon Lamp 75327
Transit Scrow (2 por act) 44350
Cilp tor transit screw (2 per set) 43855
FITTING A NEW MOTOR PULLEY
The motor pulley fits closely on the motor
spindla to maintain perfectly true running. It
the pulley cannot be lifted om without undue
difficulty aftor both fixing screws have been
slackened, insert a 4 B.A. screw In the top of
tho pully to act as an extractor and turn it with
a sctewdriver, while holding the pulley station-
‘ary, until it is ‘driven off the spindle. A suitable
extractor Is provided with the new pulley
The new pulloy should be fitted using mederate
pressure to make certain tnat itis pressed onto
‘the motor spindle as far asit will go. If difficulty
Is experienced due to the close fi, apply a
gentle heat to the base of the pulley for a short
time with a clean soldering iron, in order to
expand the pulley aufficiontly to facilitete
ving
Note that, if a new pulley has to be fitted as a
result of a change of power supply Irequency
then a stroboscopic platter ring for the new
frequency must be fitted at the same time.
Take great care in handling the new strobo-
scopic ting 0 that it does not bend. As it
held in position by impact adhesive (exposed
when protective backing removed) make sure
that the new ring is aligned exactly over the
fold one belore pressing it permanently. into
position
