Gascat ARGOS - Set Point Pressures; Accuracy and Lock up

Installation and Operation Manual
Argos - Pressure Regulating Valve
MI-23
Elaborado Verificado / Aprovado CSQ Data Revisão Página
JJ VBL JM 13/02/19 07 6 de 32
150# 300# PN 25 PN 40
19 bar 51 bar 25 bar 40 bar
The pressure limits given in this manual or in any applicable standard shall not be exceeded under any circumstances,
under risk of damage to the equipment, to the installation safety, and to people involved in the operation.
2.3.7 SET POINT PRESSURES
Pressure regulators model ARGOS can use three pilot models for pressure control G80, G30F or G32F. The table
below presents the adjustment ranges of each model:
G80 PILOT
SPRING COLOR PART NUMBER RANGE
WHITE 01.50.21G 60 - 220 mbar
BLACK 01.50.67 170 - 320 mbar
SILVER 01.50.21 230 - 400 mbar
GRAY 01.50.24 350 – 1100 mbar
G30F PILOT
SPRING COLOR PART NUMBER RANGE
SILVER 01.49.61 0.7 - 2.8 bar
GREEN 01.49.65 2 - 5.5 bar
RED 01.49.34 4.5 – 14 bar
BROWN 01.49.33 7.0 - 18.3 bar
BLACK 01.49.59 14.0 - 32.0 bar
32F PILOT
SPRING COLOR PART NUMBER RANGE
BLACK 01.49.59 14.0 - 36.6 bar
2.3.8 ACCURACY AND LOCK UP
Pressure Regulator:
AC up to 2.5%; SG up to 5%
