Gate MERF 3.2 User Manual

01. Overview
Multifunctional programmable 3rd generation MOSFET. The AEG controller has 11
functions. Its latest feature is the 3-rd Burst Mode, which allows for limiting the
number of shots. MERF 3.2 allows for lossless rate of fire adjustment. It protects
Li-Ion batteries: LiPoly and LiFePO4. It has a built-in active brake and it protects
contacts against damage. The Smart Trigger function enables achieving faster
trigger response. Thanks to two operating modes, the system works with both the
original and the modified AEG installation. The system is designed for all replicas
and especially for the upgraded ones. It has been adapted to work even with the
most powerful springs, including M170.
Main Functions Features
• MOSFET
• Active Brake
• Electronic Fuse
• Battery Protection
• Over temperature protection
• Debouncing
rd
• 3 Gen MOSFET
• ROF Control
• Smart Trigger
• 3-rd Burst
• Plug&Play
•
range of voltages 3.2 - 15V
• Compatibility with the strongest AEG
replicas
• Simple installation
• Protections
• Very low current consumption in
stand-by (0.15mA)
• Very low resistance ~2,4mΩ
• Compatible with all types of GearBox
• 4 LED Display
• DEANS-T Connectors
The system works correctly in a wide
Operating Limits Absolute Maximum Ratings
Battery Voltage
Battery Type
Spring
7.2 - 12.8V
NiCd, NiMH, Li-ion,
Li-Poly, LiFePO
4
M170, M210
Supply Voltage
Maximum continuous current
Maximum current (3 min)
Resistance
3.2 - 15V
35A
50A
2.4mΩ
USER GUIDE
05
WWW.GATEE.EU
