Gateway Convertible - Replacing the Power Button Board

Replacing convertible notebook components
34
Replacing the power button board
Tools you need to complete this task:
v
Screws removed during this task:
To replace the power button board:
1 Complete the steps in “Preparing the convertible notebook” on page 5.
2 Remove the keyboard cover by following the steps in “Replacing the keyboard cover” on
page 27.
3 Open the LCD panel to the fully open position.
4 Remove the rubber inserts from the front of the LCD panel assembly.
Important
The number of rubber inserts varies by convertible notebook model.
Flat-blade driver Scribe or non-marring tool- OR -
Phillips #0 screwdriver
2 chrome 2.5*6.0
(Power button
board)
4 or 8 black 2.5*5.0 (LCD
panel front)
Insert
InsertInsertInsertInsert
InsertInsertInsert
