CHAPTER 3: Machine Disassembly and Replacement
42
Removing the Battery Pack
To remove the battery pack:
1 Release the battery lock.
2 Slide the battery latch then remove the battery.
Removing the HDD and RAM
3 Remove three screws on the HDD cover and remove HDD.
Note
Battery has been highlighted with the yellow circle as above image
shows. Please detach the battery and follow local regulations for disposal.
To Next Page
