Replacing Gateway Notebook Components www.gateway.com
36
5 Carefully unplug the LCD video cable from the notebook. Make sure you
grasp the connector, not the cable.
6 Lift up on the video cable retaining clips slightly, then slide the video cable
from under the clips.
7 Taking care to note the cable routing and positions as they are installed
from Gateway, pull the antenna wires out from under the system board,
then slide the wires from under the retaining clips.
Retaining clip
Retaining clip
To Next Page
