Replacing the LCD panel assembly
www.gateway.com
35
Replacing the LCD panel assembly
Tools you need to complete this task:
Screws removed during this task:
To replace the LCD panel assembly:
1 Complete the steps in “Preparing the notebook” on page 5.
2 If the notebook has IEEE 802.11 wireless networking built in, unplug the
antenna from the IEEE 802.11 wireless card by following the instructions
in “Replacing the IEEE 802.11 wireless card” on page 18.
3 Remove the keyboard cover by following the instructions in “Replacing
the keyboard cover” on page 26.
Tips & Tricks
You do not need to unplug the keyboard
from the notebook.
4 Open the keyboard compartment by following the instructions in
“Replacing the keyboard” on page 28.
Flat-blade driver Scribe or non-marring tool- OR -
Phillips #0 screwdriver
1-3 black (keyboard)
2 black (keyboard cover)
4 chrome (LCD panel hinges)
To Next Page
